MindWave Mobile 2 headset houses NeuroSky’s advanced ThinkGear™ EEG technology.


Connect seamlessly with hundreds of apps across iOS, Android, PC, and Mac.

BrainPrint

Little Buddha

The Adventures of NeuroBoy

Man.Up

View Apps
Explore

Featured Apps

Effective Learner neurofeedback app icon powered by NeuroSky EEG technology

Effective Learner

Neurofeedback tool to improve study efficiency.

Explore
MindLight game app icon using NeuroSky EEG sensor for anxiety reduction

Mindlight

Neurofeedback game for kids, scientifically proven to reduce anxiety and stress.

Explore

For Developers / OEMs

The MindWave Mobile 2 delivers a powerful, developer-ready platform built on NeuroSky’s proven ThinkGear ASIC Module (TGAM). Designed for rapid integration, it provides clean, research-grade EEG brainwave data alongside our ready-to-use eSense™ algorithms for attention, meditation, and more.



This platform, supported by free SDKs, enables developers to build robust applications and develop their own custom algorithms for health, education, wellness, and entertainment.



Accelerate development with professional-level performance and signal accuracy.

Developer tools
EEG chips
Developer coding applications for NeuroSky MindWave Mobile 2 platform

Technical Specs

The MindWave Mobile 2 safely measures and outputs the EEG power spectrums (alpha waves, beta waves, etc), NeuroSky eSense meters (attention and meditation) and eye blinks. The device consists of a headset, an ear-clip, and a sensor arm. The headset’s reference and ground electrodes are on the ear clip and the EEG electrode is on the sensor arm, resting on the forehead above the eye (FP1 position). It uses a single AAA battery with 8 hours of battery life.

MindWave Mobile 2

  • Uses the TGAM1 module
  • Automatic wireless pairing
  • Single AAA Battery (Not included)
  • 8-hours battery run time
  • BT/BLE dual mode module (10 meters range). Bluetooth dongle not included.
  • Static Headset ID (headsets have a unique ID for pairing purposes)
  • Supported platforms: Windows (XP/7/8/10), Mac (OSX 10.8 or later), iOS (iOS 8 or later) and Android (Android 2.3 or later)

Measures

  • Outputs 12 bit Raw-Brainwaves (3 – 100Hz) with Sampling rate at 512Hz
  • Outputs EEG power spectrums (Alpha, Beta, etc.)
  • Outputs NeuroSky proprietary eSense meter such as Attention, Meditation, and other future meters
  • EEG/ECG signal quality analysis (can be used to detect poor contact and whether the device is off the head)

Physical

  • Weight: 90g
  • Sensor arm up: height: 225mm x width: 155mm x depth: 92mm
  • Sensor Arm down: height: 225mm x width: 155mm x depth: 165mm

Bluetooth

  • BT/BLE dual mode module
  • BT(SPP) for PC, Mac, Android
  • BLE(GATT) for iOS
  • BT Range: 10m range
